Plug the holes in your SNMP network management system - manage everything that impacts your network.
The SiteBoss 410 Enclosure Monitoring Unit helps you prevent unexpected
downtime due to non-networked, non-SNMP devices and environmental
conditions that are normally outside the scope of your SNMP network
management system (NMS). Now you can integrate these â€œotherâ€
elements into your NMS without custom programming. The SiteBoss 410
provides inexpensive insurance for your small equipment closets, remote
enclosures and other mission-critical, remote sites.
The SiteBoss 410 is specifically designed for use in small outdoor
enclosures used in todayâ€™s modern broadband and cellular
applications. The SiteBoss 410 runs on either +24VDC or -48VDC, as well
as AC power for most countries in the world. Its wide operating
temperature range makes it a good choice for cabinets in harsh
conditions. The SiteBoss 410 is priced for projects with deployments
into hundreds or thousands of sites where shaving every dollar counts.
Non-networked devices may indicate alarm states only with contact
closures. These devices are easy to monitor â€“ simply run a paired
wire between any dry contact closure output and the SiteBoss 410.
Almost immediately you can monitor backup power, electronic equipment,
door contacts, air conditioning units, generators and a variety of
Output relays help you control equipment and devices in remote
locations. You may activate lights, cameras, HVAC systems, sirens and
other devices. Output states can be controlled manually via SNMP
Temperature and humidity sensors can be used to detect threatening
conditions such as fires, floods or overheating before your critical
equipment is damaged or destroyed. Other environmental sensors may be
incorporated easily via contact closure inputs: water sensors, carbon
monoxide sensors, smoke detectors and many others.
Save hundreds of dollars per equipment rack by having the SiteBoss 410
provide power for small hubs or routers up to 1 amp in +24VDC and
Up to 23 specific SNMP Traps can be transmitted via network to your
existing SNMP management system, or the AlarmManager software provided
free by Asentria. Or you can query the 80 MIB object IDs for a more
proactive SNMP-based monitoring system.
Notable Product Features
In addition to the general overview described above, the SiteBoss 410 can address remote
management challenges with capabilities and special features such as:
SNMP-based network management systems.
- Pass-through access to one serial device
- Up to 8 on-board dry contact closure inputs
- On-Board Temperature Sensor
- On-Board Humidity Sensor
- Extended Temperature Range
- Up to 2 Voltage Sensors
- Remote Console Port Access
- Alarm Notification Options
- Free Alarm Software
- Easy Custom Modifications
- Rack Mountable
This product was added to our catalog on Friday 22 August, 2008.
